Yamaha S115V Passive Speaker


Passive PA speaker

  • 2-way 15″ speaker with 1″ compression driver horn
  • 500W cont @ 8 ohms
  • 15″ cast frame woofer
  • 2″ pure titanium diaphragm
  • 90 x 45 degree CD horn
  • Integral pole socket for stand mounting
  • Excellent for high-level music and vocals
Tag: Category: SKU: SP/LOW/YAM05


These Yamaha S115V cabinets are constructed of high quality particleboard, chosen for its high strength and elasticity, consistent void free makeup and light weight. Another great benefit of this material is its environmental friendliness. Made from southern yellow pine, this material is both abundant and quickly renewable. Accurate CNC routing machines are used to cut every part, assuring consistency with tolerances of one ten thousandth of an inch. Skilled technicians assemble each cabinet by hand, rejecting any defects. Whether covered in durable carpet or the elastomeric spray coating, heavy steel handles and sturdy pole sockets make moving and positioning easy.

The Yamaha S115V drivers are custom made by Eminence Speaker Corporation to Yamaha’s exacting tolerances. Woofers share design features like high strength curvilinear cones and Dupont Kapton voice coil formers. Oxygen-free copper voice coils and oversize strontium ferrite magnets are also used to provide high power handling and long life. The 15″ driver uses a cast aluminum frames to support the massive magnet structure eliminate flex and help dissipate heat. The compression driver that generates the high frequency sound uses a pure titanium diaphragm. This 2″ dome is one of the largest in its class, allowing for very high output and low distortion, without the aid of cooling fluids. It’s mated to a 90 degrees x 40 degrees custom designed constant directivity horn with excellent dispersion and response.

The Yamaha S115V crossover networks are constructed with oversized coils, high voltage capacitors, and power resistors designed to provide the best possible sound quality and minimize loss. Overload protection is also included to protect the components.

– – – – – – – – – – – –

2-way enclosure.
15-inch cast frame woofer.
2-inch tweeter with titanium diaphragm.
Frequency response: (-10dB) 55Hz-16kHz.
500W program handling, 1,000W peak.
Sensitivity: 99dB 1W@1meter.
Excellent for hight-level music and vocals.
Dual Speakons and 1/4″ connectors.
19″W x 28″H x 15″D
61 lbs.



DM Music Ltd are a Yamaha Commercial Audio Premier Dealer. We have been supplying Yamaha equipment for many years and regard it as one of our leading brands. If you require anything not seen below then call us on: 01582 761122
