Discontinued
  • Compact, 12″, two-way powered loudspeaker
  • 150W cont power
  • Plywood enclosure
  • Can be used as a main system or as a floor monitor.

The SxA100 provides users multiple inputs with mix capability, an easy-to-use EQ section, and loads of power in a compact, attractive package.

Features
* Designed for House of Worship, and other applications.
* Very compact, lightweight, robust polypropylene enclosure
* Real fullrange 55 Hz ¤ 20k Hz for front-of house or monitor (with F200 monitor adapter)
* Biamped with 350 W plus 80 W peak power for a very dynamic musical response
* Mixable microphone and line inputs with a 2-band EQ
* 65deg x 65deg CD horn from the famous Sx 300 for an outstanding acoustic performance
* Fully compatible with Sx mounting hardware and accessories
* Pole-mount adapter

Chassis Size 304.8 mm (12″)
Color Black
HF Amplifier Power (RMS) 50 Watts
LF Amplifier Power (RMS) 150 Watts
Speaker Type Fullrange
Speaker Type Mid-High
Speaker Type Powered Monitors
Speaker Type Powered Speakers
Speaker Type Two-Way
Frequency Response (-10 dB) 55 – 20000 Hz
Max. SPL/1m (calc) 124 dB
Coverage
(Nominal -6 dB) H- 65
Coverage
(Nominal -6 dB) V- 65
HF Transducer DH2010
Flying Yes
Outdoor No
Height 586 mm (23.07″)
Width 429 mm (16.89″)
Depth 312 mm (12.28″)
Weight Net 19.5 kg (42.99 lbs)

Brand

Electro-Voice
