Extending the ZXA1’s size-defying performance and sleek styling into the low-end realm, the ZXA1-Sub packs 700-W of self-powered punch into a low-profile wood enclosure. Match ZXA1 with ZXA1-Sub and hear just how big a small rig can sound, whether you want to add a tight thump to a DJ set or give the highs and mids some breathing room in a live performance.

• Lightweight 700-W Class-D amplifier: 126-dB maximum SPL
• 12-inch high-output woofer
• Dual XLR stereo inputs and outputs
• DSP with low-end boost and polarity control
• Pole mount for full-range systems
• 9-ply/15-mm internally braced wood enclosure with textured paint
• 46 pounds, with handle for easy carrying

Black
Power Requirement 120V: 90V¤132V, 1.0A3, 50¤60Hz 230V: 190V¤264V, 0.6A3, 50¤60Hz
Speaker Type Subwoofer
Frequency Response (-3 dB) 53Hz¤93 Hz
Frequency Response (-10 dB) 44Hz¤118 Hz
Max. SPL/1m (calc); half space 126 dB
LF Transducer (1) EVS-12S, 305mm (12Œ) Woofer
Crossover Frequency 100 Hz
Enclosure Material 9-ply, 15mm Plywood, Internally Braced, with Textured Paint
Height 400 mm (15.75″)
Width 444.5 mm (17.5″)
Depth 457.2 mm (18″)
Weight Net 20.9 kg (46.08 lbs)
Shipping Weight 26.5 kg (58.42 lbs)

Brand

EV
