Camera Controller for PTC-120
- 4D joystick for pan/tilt/zoom/focus control, ergonomic design and excellent finishing
- High brightness OLED display
- Auto backlight keys
- Multi-level protection from illegal operation or setting
- Multi-baud rates and protocols
- 7 Addresses
- Batch program cameras in the systems
- Compact design with portable features
The Datavideo mini keyboard controller is a full-function system keyboard. With features of ergonomic design, multi-function, high reliability and easy operation, it is a perfect controller for PTZ cameras, video conference cameras, surveillance cameras and etc.
The VISCA RS-232/RS-422 communication interface allows high speed, long distance communication. The benefit of RMC-190 is that it is capable of controlling up to 7 cameras connected in a daisy chain fashion.
Comm. Interface
RS-232 / RS422
Protocol
VISCA
Baud Rate
9600bps / 38400bps
Address
1~7
Joystick
4-axis (Left/Right, Up /Down, Zoom In/Zoom Out, Focus Near / Focus Far)
Display
OLED
Power
DC12V
Power Consumption
<8W
Working Temperature
0℃~ 40℃
Storage Temperature
-20℃~ 60℃
Relative Humidity
≤90% (non-condensation)
Dimensions
200mm(L)*120mm(W)*103mm(H)
Net Weight
0.5kg
Brand
Datavideo
