  • 2-way bass-reflex bi-amplified near field studio monitor
  • 5″ cone woofer and 1″ titanium dome high-frequency
  • 50Hz- 40kHz frequency response
  • 67 watts (LF 40W HF 27W) dynamic bi-amplified power
  • XLR balanced input and 1/4″ unbalanced input
Tag: Category: SKU: SP/MON/YAM09

Active Bi-amped Nearfield Monitors

Like the larger MSP7 STUDIO, the MSP5 STUDIO is a two-way bi-amplified bassreflex system that delivers outstanding monitoring precision for digital or analog production in stereo or surround formats. The more compact dimensions of the MSP5 STUDIO make it an ideal choice for smaller project studios and DAW based production systems.

The MSP5 STUDIO features a 5 inch cone woofer driven by a 40-watt amplifier and a 1 inch dome tweeter driven by a 27-watt amplifier. Other than woofer size, enclosure size, and amplifier power, the MSP5 STUDIO takes advantage of the same advanced materials and design technology that are behind the extraordinary performance of the MSP7 STUDIO.

The woofer and titanium-dome tweeter feature advanced magnetic structures that achieve exceptionally low distortion, and the tweeter works with a unique waveguide horn that achieves broad, uniform high frequency dispersion over 120 degrees for optimum balance regardless of listening position.

Advanced driver and enclosure design including the low-diffraction rounded baffle also ensure smooth, uniform dispersion across the systems full reproduction range. Flat frequency response out to 40 kHz makes the MSP5 STUDIO great for mastering, where high sample and bit rates are the norm.

Biamp 2-way Powered Speaker
Crossover Frequency – 2.5 kHz LF: 24 dB/oct, HF: 24 dB/oct
Overall Frequency Response – 50 Hz – 40 kHz (-10 dB)
Maximum Output Level – 101 dB, 1 m on Axis
Dimensions (W x H x D) – 179 x 279 x 208 mm
Weight – 7.9 kg
Magnetic Shielding – Yes
Components – LF: 5” cone HF: 1.0” Titanium dome
Enclosure – Type: Bass-Reflex Material – PP
Output Power – LF: 40 W THD = 0.02 %, RL = 4 O
Output Power – HF: 27 W THD = 0.02 %, RL = 6 O
Input Connectors, Impedance – XLR-3-31 (balanced), 10 kO PHONE (unbalanced), 10kO
Power Consumption – 60 W




DM Music Ltd are a Yamaha Commercial Audio Premier Dealer. We have been supplying Yamaha equipment for many years and regard it as one of our leading brands. If you require anything not seen below then call us on: 01582 761122
