This Professional Player Supports aptX® Coding for High Audio Quality.
Play High Quality Audio Sources Easily Using Bluetooth®
Wireless Playback of a Variety of Audio File Formats from Devices that Support Bluetooth®
Through the antenna located in the front of the CD-200BT, audio file playback signals can be received from a variety of Bluetooth® compatible devices. The types of files that can be played back depend on the transmitting device; so any file type that can be played back by iTunes, Windows Media Player, smartphone player apps and other music applications can be played through this unit.
Bluetooth® playback uses a wireless connection, so no new wiring is necessary to use compatible audio sources as long as they are in signal-range, allowing easy and speedy playback.
Note: The transmitting device must support Bluetooth® transmission.
Device Selection Function Allows Transmission Devices to Be Registered in Advance for Quick Switching and Operation
Bluetooth® playback requires pairing. Normally, pairing is one to one, but the CD-200BT has a device selection function that can be used to pair with multiple transmitting devices. By registering devices to be used in advance, you can switch smoothly between transmission devices for playback with minimal connection interruption time. （Only one device can be used for playback at a time）
In addition, since the name of the transmission device currently being used for audio playback can be shown on the display, you can check the connection status within this unit.
Wireless Playback with High Quality Audio
A variety of different profiles are used for Bluetooth® transmission depending on the application. The CD-200BT supports the A2DP (Advanced Audio Distribution Profile) for high audio quality music playback, and SBC (Sub Band Codec), a standard A2DP codec. In addition, it supports the aptX® codec, making high quality wireless audio playback possible. The aptX® codec also has an error recovery function, so audio is much less likely to be interrupted, compared to ordinary SBC transmission.
High-Quality CD Drive Designed and Built by TEAC
All models in the CD-200 series have the same highly-regarded and reliable TEAC designed CD drive. By undertaking development ourselves and including our drives in the player, we have achieved higher dependability, quality and reputation.
Supports for Numerous Audio Formats
The CD-200BT is perfect for any install scenario where audio format versatility is needed.
Playback media CD,CD-R,CD-RW (8/12cm)
CD-DA Stereo, 44.1kHz, 16bit
WAV(Data CD) Stereo, 8/16/32/11.025/22.05/44.1/12/24/48kHz, 16bit
MP2(Data CD) Stereo, 32/44.1/48kHz、32-384kbps
MP3(Data CD) Stereo, 32/44.1/48kHz、32-320kbps, VBR
Analog audio input
Connector 1/8″(3.5mm) Stereo Mini Jack
Input impedance 22k ohms
Nominal input level -20dBV
Maximum input level -4dBV
Analog audio output
Connector RCA pin-jack
Output impedance 200 ohms
Nominal output level -10dBV(0.32Vms)
Maximum output level 6dBV(2.0Vms)
Digital audio output
Connector RCA pin-jack
Connector TOS(JEITA RC-5720C)
Output Class Class 2
Supported profile A2DP、AVRCP
Supported A2DP codec SBC、AAC、aptX®
Supported contents protection SCMS-T
Connector 6.3mm(1/4″) stereo phone jack
Maximum output level 20mW 20mW (THD 0.1%, 32ohms loaded)
Power AC120V, 60Hz (North American)/AC230V, 50Hz (EUR)/AC240V, 50Hz (Australia)
Power consumption 11W
Operating temperature 5-35˚C
Inclination of installation 5˚ or less
Standard accessories Wireless remote controller(RC-CD200BT), AA battery, Rack mounting screw kit, Warranty card, Owner’s manual
Frequency response 20Hz-20kHz, /-1dB(playback, JEITA)
Distortion 0.01% or less(playback, JEITA)
S/N ratio 90dB or greater(playback, JEITA)
Dynamic range 90dB or greater(playback, JEITA)
Channel separation 90dB or greater(playback, JEITA)
