The PT−110xl is an extended range UXGA line transmitter that receives a UXGA signal and transmits it over a CAT 5/6 cable to the PT−120xl or TP−120 receiver.
Resolution – Up to WUXGA & 1080p.
Power Connect™ System – A single connection to the transmitter or the receiver powers both units when the devices are within 150ft (50m) of each other.
Extended Transmission Range – Up to 250m (820ft) when used with Kramer’s twisted pair xl receivers (such as PT−120xl, TP−122xl or TP−126xl).
EDID Capture – Copies and stores the EDID from a display device.
Increased Noise Immunity – An increased level of protection against noise, spikes and interference in adverse environments.
Size – Ultra-Compact Pico TOOLS™ – 4 units can be rack mounted side−by−side in a 1U rack space with the optional RK−4PT rack adapter.
Applications: Presentation and multimedia applications. Long range graphics distribution for schools, hospitals, security, and stores.
INPUT: 1 VGA/UXGA on a 15−pin HD connector. OUTPUT: 1 RJ−45 LINE OUTPUT connector. RESOLUTION: Up to WUXGA & 1080p. S/N RATIO: 69dB (worst case). COUPLING: AC. POWER CONSUMPTION: 12V DC, 320mA. DIMENSIONS: 6cm x 6.5cm x 2.5cm (2.36″ x 2.56″ x 1″) W, D, H. WEIGHT: 0.14kg (0.31lbs) approx. INCLUDED ACCESSORIES: Power supply. OPTIONS: RK−4PT 19−inch rack adapter.
