Name: DBX Driverack 220i
SKU: OB/PRO/DBX07FP
Price: 699.00 GBP
Availability: BackOrder

Discontinued

System Proccessor with Advanced Feedback Suppression

The DriveRack 220i is the perfect tool for any fixed-install application.

Tag: DiscontinuedCategory: Speaker Management / DSPSKU: OB/PRO/DBX07FP

Designed from the ground up to provide state-of-the-art signal processing, the DriveRack 220i is the perfect tool for any fixed-install application. With a full complement of processing features and Mic/Line inputs the DriveRack 220i can provide both system and microphone processing. Featuring the new, patent-pending Advanced Feedback Suppression (AFS) algorithm, equalization, dynamics processing, delay, matrix mixing, and bandpass filters, the DriveRack 220i will exceed your expectations.

<p >The DriveRack 220i is piloted from the intuitive DriveWare GUI that offers both Configuration and Control of the processing modules. Modules can be accessed, edited and saved as part of programs. Processing modules can be linked between the channels for true stereo processing. If independent processing is desired, parameters can be copied from one channel to the next to ensure that setup is quick and easy. Stored programs can be loaded from either the front panel or from wall mounted Zone Controllers. Zone Controllers can also be used for output muting or adjusting output volumes.

Advanced Feedback Suppression (AFS)
Graphic and Parametric EQ
Compressor
Limiter
Auto Gain Control
Noise Gating
De-Esser
Ducker
Bandpass Filters
2×2 Matrix Mixer
1.3 Seconds of Delay
Mic/Line Inputs
Wall Panel Control
Security Lockout

Input	(2) Switchable line or mic inputs
Input Connectors	Female XLR line inputs and Euroblock
Input Type	Electronically balanced/RF filtered
Input Impedance	>50k ohm
Max Input	20dBu
CMRR	> 40dB, typically >55db @ 1kHz
Mic Preamp gain	30 to 60dB
Mic Preamp Equivalent Input Noise (EIN)	< -110dB, 22Hz-22kHz, 150 ohm
Mic Preamp Phantom Power	15VDC
Output	2 total
Output Connectors	Male XLR and Euroblock
Output Type	Electronically balanced, RF filtered
Output Impedance	120ohm balanced, 60ohm unbalanced
Max Output	20dBu
A/D Converter	dbx Type IV™ Conversion System
A/D Dynamic Range	(line) >113 dB, A-weighted, >110 dB unweighted
Type IV Dynamic Range	>119 dB, A-weighted, 22kHz BW; >117 dB, A-weighted, 22kHz BW
Sample Rate	48kHz
D/A Dynamic Range	112 dB A-weighted, 109dB unweighted
Dynamic Range	>110 dB A-weighted, >107dB unweighted
THD Noise	0.003% typical at 4dBu, 1kHz, 0dB gain
Frequency Response	20Hz – 20kHz, /- 0.5dB
Interchannel Crosstalk	>110dB, 120dB typical, (input-to-output: >780dB)
Operating Voltage	100 VAC, 50/60Hz, 120 VAC, 60Hz, 230VAC 50/60Hz
Dimensions	19” Wide, 1.75”High, 7.7” Deep
Safety Agency Certifications	UL 6500, IEC 60065, EN 55013, E 60065
