Compact charger incl. USB port and LCD display to show all important data
The microcontroller-monitored charger of Powerline series does not require any control elements and, thanks to the fully automatic control, its handling is clear and easy. Mignon AA and Micro AAA batteries can be charged simultaneously; they can also be mixed. The battery level prior to charging is irrelevant. The charger is suitable for all brand batteries (NiMH/NiCd) and rechargeable batteries.
Intelligent charge control
Charging starts automatically after the batteries are inserted. Once a battery is fully charged, the charging process is automatically stopped and switched to trickle charging (buffer charging with current impulses). This feature ensures optimum performance and counteracts the self-discharge of the battery. The battery can thus remain in the device until it is used.
The Powerline 4 Light is designed for worldwide use. Its wide input range, compact size and extremely low weight makes it ideal as a travel companion and a replacement of several chargers at a time thanks to the USB charging socket.
Highlights of the ANSMANN Powerline 4 Light
Charging the batteries: Charging option for 1-4 Micro AAA / Mignon AA NiCd/NiMH batteries.
Automatic shut-off: State of the art microprocessor-controlled charging technology with multiple overcharge protection guarantees optimally charged batteries and a gentle charging process.
USB charging socket: The USB port offers the possibility to also charge mobile devices with fixed batteries, such as smart phones.
Individual monitoring: In Powerline 4 Light each round cell (either AAA or AA) can be placed in any charging slot. Each battery is individually monitored during charging, and individually charged to its maximum capacity.
LCD display: Shows the current battery voltage and the current battery level in 5% increments alternately for each charging slot, thereby providing a reliable control of the charging process. It also alerts you when a non-rechargeable battery is inserted, or when a battery is faulty.
AA Max e Batteries
Optimal solution for demanding users: The batteries have a high capacity, and still a very low self-discharge. It is thus ideal for applications such as flashlights, toys, modelling, game consoles, digital cameras, flash equipment, medical equipment etc. maxE has the energy to power all your devices. The self-discharge is 10 times lower than in regular NiMH batteries. After a year, there is still around 80% of the initial capacity left. This was made possible by a special separator which dramatically reduces unwanted internal current flow.
NiMH batteries can generally be used wherever disposable batteries are used. This allows you to save money and protect the environment. A rechargeable battery can replace many hundreds to thousands of batteries!
The batteries naturally meet the currently applicable EU Directive and the highest standards of safety and durability. Thanks to the excellent cycle stability, the NiMH cells can be recharged up to 2100 times. Since the batteries are supplied pre-charged, they can be used directly.
The batteries can be used at temperatures from -20° C to 50° C. The cells are successfully tested by TÜV Saarland for compliance with electrical, thermal, geometric and safety-related requirements.
The batteries can be charged with a high charging current, thereby very short charging times are possible. With the latest battery technology, the memory effect is ruled out even after several partial charges.
Chargeable cells AAA | AA | USB
Input voltage 100-240V AC
Worldwide use Yes
LCD display Yes
Individual supervision of cells Yes
Over-charging protection (trickle charge) Yes
Faulty cell detection Yes
Microprocessor control Yes
Safety timer Yes
Current Micro AAA 450mA (1-4)
Current Mignon AA 450mA (1-4)
Current USB 1000mA (1)
